Elegant Timber Plank-AI159048

Natural Warmth with Refined Sophistication
Elegant Timber Plank brings the timeless beauty of natural wood into any interior space, offering a refined aesthetic without compromising on durability. With its graceful wood grain patterns and warm, earthy tones, this collection adds a touch of sophistication and natural charm to modern and classic environments alike.
Durable Design for Everyday Living
Crafted using high-quality porcelain, Elegant Timber Plank is resistant to moisture, scratches, and stains—making it an ideal solution for both residential and commercial spaces. The rectified edges ensure seamless installation with minimal grout lines, enhancing the clean, spacious look of your floors or walls.
Versatile Application Across Spaces
Whether you're designing a cozy living room, a welcoming retail space, or a serene spa environment, Elegant Timber Plank adapts beautifully to any setting. Available in various plank sizes and natural hues, it delivers both the authenticity of timber and the long-lasting performance of porcelain.
Color:
SKU:
Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • AI159048


|

 Specifications


Collections AI159048
Size(mm) 150x900mm
Thickness(mm) 9.5±0.2mm
Materials Porcelain
Finishing Structure Matt
Pattern 18
Style Wood Look Tile
Tile Body White Body
Shape Plank
Application Place Suitable for floors and walls in living rooms, bathrooms, kitchens, and commercial spaces.
Loading Port Foshan Port


|

 Implementation Standards

TECHNICAL SPECIFICATIONS


DESCRIPTION STANDARD TEST MEASUREMENT UNIT ISO STANDARD REQUIREMENT logo1
Length& Width ISO 10545-2 mm ±0.5%Max ±5.0%Max
Thickness ISO 10545-2 mm ±5.0% Max ±5.0%Max
Sides Straightness ISO 10545-2 mm ±5.0% Max ±5.0%Max
Rectangularity ISO 10545-2 mm ±0.6%Max ±0.6%Max

Flatness: a) Centre Curvature

b) Edge Curvature

c)Warpage

ISO 10545-2

ISO 10545-2

ISO 10545-2

mm

mm

mm

±5.0% Max

±5.0% Max

±5.0% Max

±5.0%Max

±5.0% Max

±5.0% Max

Surface Quality ISO 10545-2 One major area of tles ≥95% free from visible defect 95% free from visible defoct
Water Absorption ISO 10545-3 Mass ≤0.5% 0.5%
Modulus of Rupture ISO 10545-4 N/mm2 ≥35N/mm2 ≥35N/mm2
Deep Abrasion ISO 10545-6 mm3 175 mm3 ≤175mm3
Surface Abrasion PEI ASTM C1027 ISO 10545-7 Visual Check Manut. to state Abrasion Class,Cycle Passed Manut. to state Abrasion Class,Cycle Passed
Crazing Test ISO 10545-11 Visual Check Not Applicable for porcelain tiles Not Applicable for porcelain tiles
Frost Resistance ISO 10545-12 Visual Check Required Required
Chemical Resistance (Low Cons.) ISO 10545-13 Visual Check Manuf.to state Manuf. to state
Chemical Resistance(Household/Swimming Pool) ISO 10545-13 Visual Check Max Visible Change On Cut Side Max Visible Change On Cut Side
Stain Resistance ISO 10545-14 Visual Check Class 3 Min Class 3 Min
Coefficient of Friction ISO 10545-17 Manuf.to state Manuf.to state Manuf.to state


|

 Production Pictures


1-Fineness-Test-of-the-Slurry

Fineness Test of the Slurry


To check if the slurry particle size meet the requirement of spray drying.


2.Breaking-Strength-Test-of-Green-Body

Breaking Strength Test of Green Body


To make sure the green body is strong enough before glazing and printing.


3.Flow-Velocity-Test-of-Glaze

Flow Velocity Test of Glaze


To determine if the glaze slurry is evenly grinded.


4.Specific-Gravity-TestSpecific Gravity Test


To test if the density of the glaze meet the requirement of formula.


Weighing-of-Applied-Glaze Weighing of Applied Glaze


To weigh the glaze applied on each tile and determine if it needs adjustment.


6.Flatness-&-Squareness-TestFlatness & Squareness Test


To check the flatness and squareness of each tile after rectifying via the state-of-art automatic machine.


2Shade Difference Inspection


To check the shade difference then sort them by shade number.


1 Container Loading Inspection


To check the status of the container and the details of loading.



|

 Inspection Pictures


measurement
measurement


measurement
measurement
measurement

measurement


|

 Packing and Loading


loading1
loading
loading3

loading2



|

 Projects


未标题-1


Princip Hotel in Panama


Project Location: Panama


Project Type: Princip Hotel


Product Used: Beige Cement Tiles-3245SQM


WIFi Ceramics New Project - Starbucks Coffee Shop (4)


WIFi Ceramics New Project - Starbucks Coffee Shop


Project Location: Zhejiang, China


Project Type: Coffee Shop


Product Used: Terrazzo Tiles - 320 square meters



WiFi Ceramics New Project - Starbucks Coffee Shop - Terrazzo Tiles


WIFi Ceramics New Project - Starbucks Coffee Shop


Project Location: Suzhou, China


Project Type: Coffee Shop


Product Used: Terrazzo tiles - 450 square meters


travertine porcelain basin7


High-end villa in Cambodia


Project Location: Cambodia


Project Type: Villa


Product Used: Travertine Porcelain Tile-180SQM


multicolor terrazzo tile


Apartment in Brunei


Project Location: Brunei


Project Type: Apartment


Product Used: Colorful Terrazzo Tile-2000SQM


cement tile flooring - 副本


Kuwaiti Chain Bakery


Project Location: Kuwaiti


Project Type: Bakery


Product Used: Cement Tile-400SQM
